XB BMS

Made in the U.S.A.

Overview

The XB Battery Management System (BMS) is the proven control platform used across Lithion Custom packs.‍

‍

Proprietary to Lithion and fully developed in the U.S., the XB BMS combines in-house hardware and firmware engineering to deliver advanced monitoring, protection, and communication for systems ranging from 12 V to 1500 V.

Get a quote
View Full Specifications

Features

  • Tailored for Lithium Iron Phosphate (LFP) chemistry
  • Can operate packs and strings in series and parallel configuration
  • Designed in system redundancy for assured operations
  • Controls up to 5 system and 3 string-level contactors
  • Monitors up to 64 modules (12–48 V each) with 8 temperature sensors per module
  • High-accuracy measurements: ±2 mV cell voltage, ±20 mA current
  • Passive cell balancing (250 mA) with heating control
  • Built-in protection for over/under-voltage, isolation, and temperature faults
  • Dual-microcontroller safety with HVIL detection
  • Data logging and event recording via SD card
  • Real-time monitoring: SOC, SOH, cell voltages, and temperature limits
  • Supports multiple communication protocols: CANBus, Ethernet, RS485, Modbus TCP, CANopen
  • Compact, stackable design for integration into battery packs or power distribution units
